CHASSIS

Frame Molybdenum steel with double cradle split above
the exhaust port

Wheelbase 1482 mm

Max length 2172 mm

Max width 815 mm

Max height 1270 mm

Seat height 950 mm

Ground clearance 320 mm

Footrest height 407 mm

Dry weight 103,5 kg (front 50,8 kg; rear 52,7 kg)

Fuel tank capacity 9,5 L

Reserve 2,3 L

Cooling system capacity 1,3 L

Front suspension Hydraulic USD fork with ø 48 mm shaft

Rear suspension Monoshock with progressive compound lever

Shock absorber stroke 135 mm

Front wheel travel 295 mm

Rear wheel travel 290 mm

Front brake Wave disc ø260 mm and double-piston floating
caliper

Rear brake Wave disc ø240 mm and single-piston floating
caliper

Front rim 21 x 1,6 – 36 holes

Rear rim 18 x 2,15 – 36 holes

Front tire 90/90 – 21

Rear tire 140/80 -18

ENGINE

Type Single cylinder, 2-stroke, liquid-cooled

Bore 66,4 mm

Stroke 72 mm

Displacement 249 cc

Compression ratio 13,2:1

Exhaust Valve BPV System

Starter Electric starter

Ignition AC Kokusan – digital CDI with oil pump controller

Spark plug NGK BR8ES

Induction system induction reed

Lubrication Mixing

Carburettor Keihin PXK 36

Clutch wet multi-disc clutch

Primary drive Z.27/72

Transmission 6 gears

Final transmission chain

Engine oil SAE 10W/40

Consumption l/100 km 2,493

Pollution Co2 [g/km] 59
